UC200 Pro IP PBX for SMEs

The UC200 Pro is specifically designed for small and medium-sized enterprises, providing 2 FXS and 2 FXO interfaces and allowing users to expand with 2S/20/1S1O modules by supporting up to 3 additional modules to flexibly meet various communication needs. It supports up to 500 SIP users and 50 concurrent calls (with up to 25 concurrent calls in full recording mode), ensuring excellent call quality even under high load conditions. The UC200 Pro realizes remote offices through SIP voice terminals and can seamlessly integrate with other IPPBXs or traditional PBX systems, catering to the diverse communication requirements of enterprises while employing advanced encryption and security strategies to fully ensure communication security.

• Key Features and Benefits:

  • Capacity & Expansion: Supports up to 500 SIP users and 50 concurrent calls, with expandability using 2S/2O/1S1O modules (up to 3 additional modules).

  • Flexibility & Efficiency: Flexible dial rules based on time, number, or source IP, supporting multi-level IVR interactive voice response, voicemail, and voice recording.

  • User Management: User-friendly web interface with classification of web user rights.

• Technical & Physical Specifications:

  • Physical Interfaces: 2 FXS ports, 2 FXO ports (expandable with up to 3 additional modules via 2S/20/1S1O slots), 2*10/100/1000M Base-T RJ45 Ethernet ports, 1 TF card slot, 1 USB 2.0 interface, and 1 RS232 console port (115200bps).

  • Power Supply & Consumption: Power supply of 12VDC, 2A; power consumption of 10W.

  • Dimensions & Weight: Dimensions (W/D/H) of 260x154x42mm and unit weight of 1.1kg.

  • Operating Environment: Operating temperature from 0°C to 40°C, storage temperature from -20°C to 80°C, and humidity from 10% to 90% non-condensing.
